What are Turbochargers?
It is a efficient method forcing more air into the combustion chamber, allowing more fuel to equal non atmospheric power gains that is driven by normally wasted gas energy. Each cylinder pulse, normally being wasted, is used to power a compressor wheel, then forcing air into the manifold.
What is the difference between Superchargers and Turbochargers?
A supercharger is mounted to the engine and is driven by a pulley that is inline with the crank.
A turbo is driven by exhaust gasses that have been expelled by the engine and are travelling through the exhaust manifold
Why should I use a Turbocharger vs a Supercharger?
The turbocharger is generally more economical and efficient to operate as it as it is driven primarily by potential energy in the exhaust gasses that would otherwise be lost out the exhaust, whereas a supercharger draws power from the crank, which can be used to turn a compressor wheel. The turbocharger’s impeller is also powered only under boost conditions, so there is less parasitic drag while the impeller is not spinning. Turbochargers do not use power to make power, it uses merely wasted energy that would otherwise be unused.
Will this fit my car?
This is a universal starter kit. We provide the fundamentals to develop your own custom kit to your specific vehicle or special specifications. Everything in this kit will be used in developing of a custom turbo kit.
What else would I need to make this fit my car?
Some applications will require custom manifold or modifications to reuse your OEM manifold to retrofit it to the turbo. This would require a custom downpipe that can be easily made at a local muffler shop for a fraction of the cost. All non-turbocharged applications will require some sort of fuel management, either mechanical or electronic, to add extra fuel for the extra air to equal power gain.
Package comes with Everything shown from the picture above (color may vary on some items)
NOTE: This is a universal Kit. You will need Turbo Down Pipe, and Turbo Manifold to complete the Turbo Kit Project
Item Detail:
100% Brand New Kit, High Quality, Never Been Used or Installed!!
The packages Includes:
1 x T3/T4 Hybrid Turbo Charger: 100% Brand New T3/T4 Hybrid Turbocharger! High Quality Guaranteed! This turbo can easily do 25 PSI, and 500+ hp on b series swaps, standard t3/t4 flange, perfect for any 4-6 cylinder applications. Power performance output capability = 25-35 psi. Cnc machined flanges. High quality t04e with a forged turbine propeller wheel!
Turbo Specification:
-Inlet Diameter: 3″
-Outlet Diameter: 2″
-Oil Inlet: 1/8 NPT
-Compressor Wheel: .57 Trim
-A/R Compressor: .50 A/R
-A/R Turbine: .63 A/R
Turbine wheel:
-Exducer: 2.48″
-Mayor: 2.89″
Compressor wheel:
-Exducer: 2.07″
-Mayor: 2.36″
1 x Intercooler: Light Weight. Size 27” x 7” x 2.5” inch. Inlet size is 2.5 inch.
Support up to 350 hp for this small intercooler size – tube and fin style .
1 x Universal turbo intercooler piping kit: Made of 6061 aluminum.
2.5 inch diameter piping kit with high quality silicone couplers and T-bolt clamps.
The couplers will not split easily + the clamps will not strip like the cheap kind.
Strong & tighter fitting use hair spray between the pipe and coupler.
Mandrel bend for high flow and high horse power and better turbo response power.
1 x TYPR-S Blow Off Valve: Brand New, Light Weight, High Quality CNC Billet Aluminum Type RS Style Blow off Valve and 2.5″ Inch Type S/Rs Flange Pipe. Easy Mount Piping Set Included For Bolt-On. Including all necessary hardwares. Our Blow Off Valves Are easily adjustable to prevent both permature boost leakage and compressor surge. Fast Fesponse One For Low And High Boost Pressure. 25PSi Boost! Can hold up to 1000+ HP.
1 x 38MM Wastegate: Brand New, High Quality GT-Series 38mm External Waste Gate Kit. The Waste Gate is in accurate boost control and high quality appearance features Dual port design, accurate boost, ultra durable diagram (diaphram). It comes with waste gate spring (fully adjustable, up to 15 psi), allow you to add the spring to get desired high psi.
1 x Turbo Boost Controller: Brand New, Light Weight, High Quality CNC Billet Aluminum Manual Turbo Boost Controller. Adjustable boost knob increases horsepower and torque, depends on boost level. Allows adjustable boost PSI setting, can be easily mount under the hood.PSI Level: Up To 30 PSi Boost.
1 x Turbo Oil Return / Feeding Line Kit: Brand New, Light Weight, High Quality Turbo Oil Feed + Return Drain Line Kit Combo. It helps circulate oil from the turbo charger to the oil pan. The kit provides a anodized look, and gives a best cooling performance on your turbo and long lasting life.
Material: Stainless Steel Braided.
1 x 5-Bolt Flange: Brand new 2.5” 5 BOLT TURBO DOWNPIPE FLANGE.Make of high quality light weight CNC-machined mild steel.Thickness: 1/2”.Inlet Diameter: 2.5”.Bolt Size: 3/8”.
1 x 4-Bolt Flange: Brand new T3/T4 T04E T3 TURBO FLANGE.Make of high quality light weight CNC-machined mild steel. * Thickness: 1/2”. Bolt Size: 3/8”.
Installation: Instruction is Not Included, Professional Installation is highly recommended.
