AEM Series 2 Plug & Play EMS – Plug & Play Engine Management System
30-6040
Series 2 Plug & Play Engine Management Systems
AEM’s Series 2 EMS is a complete engine
control system that plugs into the factory harness and uses the factory
sensors. This means you do not need to replace any parts of the harness
or sensors, just plug the EMS into the harness and begin tuning! The
Series 2 EMS allows you to control every aspect of your engine. From
VTEC to rev limit, timing, adding different sized injectors, boost
control, nitrous injection, even anti-lag and individual cylinder fuel
and timing trims, the Series 2 EMS gives you total control from an easy
to use interface.
Legal in California only for racing vehicles which may never be used upon a highway.
This product fits the following vehicles:
1992 to 1993 Acura Integra GSR 1.8L 1994 to 1995 Acura Integra GSR 1.8L1992 to 1993 Acura Integra GSR 1.7L1992 to 1993 Acura Integra RS, LS, GS 1.8L 1994 to 1995 Acura Integra RS, LS, GS 1.8L 1990 to 1995 Honda Accord DX, LX, SE, EX 2.2L 4 Cyl 1992 to 1995 Honda Civic DX, LX 1.5L 1992 to 1995 Honda Civic EX, Si 1.6L VTEC1993 to 1995 Honda del Sol Si 1.6L SOHC VTEC 1994 to 1995 Honda del Sol VTEC 1.6L DOHC VTEC1993 to 1995 Honda del Sol S 1.5L 1992 to 1995 Honda Prelude H22 1990 to 1991 Honda Prelude Si 2.1L 1992 to 1995 Honda Prelude H23 1992 to 1995 Honda Prelude F22
Outputs
Injector Outputs12 Saturated
Coil Outputs 4
Selectable direct drive or 0-5V Coil OutputYes
Direct plug in, no jumper harness requiredYes
General purpose LS outputs12
General purpose HS outputs4
Individual cylinder ignition trimsYes
Individual cylinder fuel trimsYes
Inputs
Trigger inputs (Ref/Sync)4
Analog voltage inputs23
Configurable Analog/RTD/Thermister inputs 4
Switch inputs 5
Lambda inputs 2x
Knock sensors 2
User adjustable knock sensor center frequency Yes
Communication
USB comms Yes
RS232 comms Yes
Communication cables included Yes
Fully enabled editing/logging software included Yes
CAN bus equipped Yes
RS232 datastream output 19 ch
CAN datastream output 19 ch
Communicates with AIM Dash/Dataloggers Yes
Communicates with Racepak Dash/Dataloggers Yes
DATA Acquisition
Internal data logging 1 MB
Maximum internal logging rate (per channel) 250 Hz
PC logging Yes
Data analysis using AEMLog Yes
Functions and Features
All channels/maps/tuning options unlocked Yes
Boost control Yes
Groundspeed based boost target Yes
Staged injection Yes
Ground speed limiting Yes
Rate of Acceleration Control Yes
Overrun boost enhancement (anti-lag) Yes
Gear change ignition cut (shift-without-lift) Yes
Password protected calibrations Yes
Fuel & Ignition rev limiters Yes
“In cockpit” global fuel trim capability Yes
Gear dependent shift light Yes
Evap/Purge function Yes
DC Motor control 2 Ch
Software definable “virtual” switch inputs 2
EGT Based fuel trims Yes
Maximum boost limit None
Physical Dimensions
Length 192 mm
Width 150 mm
Height 37 mm
Finish Black Anodized
AEM’s Series 2 Programmable Engine Management System is more powerful than
its predecessor. In addition to more robust hardware, there are several
improvements over the original EMS, noted in the chart below. Like its
predecessor, AEM’s Series 2 Plug & Play EMS plugs directly into a
vehicle’s factory ECU harness and requires no additional wiring or
hardware. Windowsâ„¢ compatible software (XP, Vista, Windows7) makes the
task of copying, viewing and manipulating data as simple as a click of
the mouse. Our new AEMTUNER
software is infinitely adjustable software and allows tuners to program
virtually any combination of engine control, power adders and auxiliary
devices, and accurately delivers proper amounts of fuel and correct
ignition timing for any boost level or operating condition.
Legal in California only for racing vehicles which may never be used upon a highway.
SERIES 2 KEY FEATURES
Plugs directly into the factory harness. No rewiring necessary.Uses all the factory sensors.Includes start up calibrations.System is fully enabled and unlocked – Never pay for upgrades!Context sensitive help eases tuning process.Maps can be password protected by the tuner to prevent unauthorized usage or sharing.Runs on Windows-compatible software.Up to 12 peak and hold injector drivers.Up to 8 direct-fire coil outputs.Up to 16 general-purpose outputs.Up to 8 definable switch inputs.Up to 4 EGT inputs with fuel control.1MB of internal data logging.Electronic boost control.Full idle control.Programmable traction control.Software definable knock control.Two step launch control.User configurable soft-cut rev limiters.Wet or dry nitrous control.Tune using new USB communication port or serial port.Works with all AEM gauges.
